ST-VI2000-24 — 2 kW 24 V Pure Sine-Wave Vehicle Inverter
Pure-Sine, Grid-Stable, Efficient.
Technical Specifications
18 months from date of invoice.
Detailed Specifications
PARAMETERS
| PARAMETER | VALUE |
|---|---|
| Rated Output Power | 2000 W |
| Nominal Battery Voltage | 24 Vdc |
| Rated Input Voltage | 22–32 Vdc |
| Output Voltage | 220 Vac ±5% |
| Output Waveform | Pure sine wave |
| Output THD | ≤ 3% |
| AC Output Frequency | 50 ±1 Hz |
| Efficiency | 92% |
| No-load Current | ≤ 500 mA |
| Overload Protection | 3000 W +10% |
| Startup Delay | < 2 s |
| AC Output Channels | 1 or 2 (selectable) |
| Ingress Protection | IP5K3 |
| Cooling | Forced air cooling |
| Operating Temperature | -40 to +70 °C (derate above 50 °C) |
| Storage Temperature | -40 to +85 °C |
| Weight | 2.6 kg |
INTERFACE
| INTERFACE | VALUE |
|---|---|
| DC Input | + / − (24 V battery, 22–32 Vdc) |
| AC Output | 220 Vac, 1 or 2 channels (selectable) |
PROTECTIONS
| PROTECTION | DESCRIPTION |
|---|---|
| Overload | Protection at 3000 W +10% |
| Ingress Protection | IP5K3 sealed housing |
FEATURES
| FEATURE | VALUE |
|---|---|
| Cooling | Forced air cooling |
| Output | Pure sine wave, 220 Vac ±5%, THD ≤3% |
| Application | 24 Vdc → 220 Vac; sustains 2 kW; suits induction cookers / microwaves ≤2400 W |
| Output Channels | 1 or 2 selectable AC output channels |
Additional Details
The ST-VI2000-24 is a 2 kW, 24 V pure sine-wave vehicle inverter that converts a 24 Vdc battery (22–32 Vdc input) into a clean 220 Vac ±5% output at 50 ±1 Hz. With THD ≤3% and 92% efficiency, it delivers grid-quality power for sensitive and high-draw appliances, sustaining a continuous 2 kW load and driving induction cookers and microwaves up to 2400 W.
Built for mobile and off-grid use, the inverter features an IP5K3 sealed housing rated for -40 to +70 °C operation (derating above 50 °C), forced-air cooling, a no-load current of ≤500 mA, overload protection at 3000 W +10% and a startup delay under 2 s. Selectable 1- or 2-channel AC output makes it a versatile building block for vehicle, RV and backup power systems. Weight 2.6 kg.
Frequently asked questions
What is the ST-VI2000-24 — 2 kW 24 V Pure Sine-Wave Vehicle Inverter?
The ST-VI2000-24 is a 2 kW, 24 V pure sine-wave vehicle inverter that converts 24 Vdc to 220 Vac — clean ≤3% THD output, 92% efficiency and an IP5K3 sealed housing for mobile, off-grid and automotive power, running induction cookers and microwaves up to 2400 W.
What are the key specifications of the ST-VI2000-24?
Output — 2000 W · 220 Vac pure-sine · 24 Vdc · 92% · THD ≤3% · IP5K3. Input — DC 22–32 Vdc (24 V) · No-load current ≤500 mA · Overload protection at 3000 W +10%.
What are the ST-VI2000-24's efficiency, ingress protection and operating conditions?
Peak efficiency: 92%. Operating temperature: -40 to +70 °C (derate above 50 °C). Cooling: Forced air cooling.
What communication interfaces does the ST-VI2000-24 support?
1 or 2 selectable AC output channels; startup delay <2 s.
What protection features does the ST-VI2000-24 include?
Built-in protections: Overload, Ingress Protection.
What is the warranty on the ST-VI2000-24?
18 months from date of invoice.
